型号 |
ZKW-10 |
ZKW-20 |
ZKW-30 |
ZKW-40 |
ZKW-50 |
ZKW-60 |
ZKW-70 |
ZKW-80 |
||
|
箱
体 |
额定风量m3/h |
10000 |
20000 |
30000 |
40000 |
50000 |
60000 |
70000 |
80000 |
|
|
公称冷量kw |
58.15 |
116.28 |
174.42 |
232.56 |
290.75 |
384.84 |
407.05 |
465.12 |
||
|
公称热量kw |
69.78 |
139.53 |
209.30 |
279.07 |
348.84 |
418.61 |
488.37 |
558.14 |
||
|
断面尺寸mm |
高 |
1500 |
1700 |
2100 |
2300 |
2600 |
2700 |
2800 |
2900 |
|
|
风机 |
宽 |
1580 |
1780 |
2180 |
2380 |
2680 |
2780 |
2880 |
2980 |
|
|
型号 |
KKF-450 |
KKF-630 |
KKF-710 |
KKF-900 |
KKF-900 |
KKF-1000 |
KKF-1000 |
KKF-1120 |
||
|
风量适用范围m3/h |
8255-16992 |
16411-25026 |
25115-36020 |
34030-45941 |
45941-57852 |
57038-69590 |
63438-75680 |
70548-88838 |
||
|
冷却水接管 |
2排 |
Dg50 |
Dg50 |
Dg50 |
Dg50 |
Dg65 |
Dg50 |
Dg50 |
Dg65 |
|
|
管道接口 |
4排 |
Dg50 |
Dg65 |
Dg65 |
Dg65 |
Dg80 |
Dg65 |
Dg65 |
Dg80 |
|
|
8排 |
Dg50 |
Dg65 |
Dg65 |
Dg65 |
Dg80 |
Dg65 |
Dg65 |
Dg80 |
||
|
水蒸汽加热接管公称尺寸mm |
Dg50 |
Dg50 |
Dg65 |
Dg80 |
Dg80 |
Dg100 |
Dg100 |
Dg100 |
||
